Technical Specification

Model		RTL-300GN	RTL-300GE	RTL-450GE
Motor	Type	Carbon Brush	Carbon Brush	Induction
	Specification	1100w1 ø	1100w1 ø	750w3 ø
Conveying Capacity		400	350	400
Static Wind Pressure (Max)		1500mm Aq	1500mm Aq	1500mm Aq
Filter		ø 185x115H	ø 185x90H	ø 185x90H
Volume of Material Hopper (L)		6	6	6
Inside Diameter of Conveying Pipe (mm)		ø38	ø38	ø38
EXternal Size	Main Body LWH	480x310x430	500x400x600	500x400x800
	Material Hopper LWH	430x440x295
Weight	Main Body	15.5	13.5	18.5
	Material Hopper	5
Note : We reserve the right to make some changes of products specifications without notic
